18650 3.6V 6000mAh BAK Lithium Battery Pack for Smart Door Lock

Customization | Free Battery Solution

Product Detail

Project number: 01DQ0023-50T

Cell model: N18650CP/3250mAh/3.6V

Battery specifications: 18650-1S2P/6000mAh/3.6V

Nominal voltage: 3.6V

Nominal capacity: 6000mAh

Charging voltage: 5V to 4.2V charging

Charging current: ≤3.35A

Discharge current: 3.35A

Instantaneous discharge current: 7.5a

Discharge cut-off voltage: 3.0V

Internal resistance: ≤250m ω

Battery weight: 130G

Product dimension: 22.2*42.0*77.9 mm

Charging temperature: 0 ~ 45℃

Discharge temperature: -20 ~ 60℃

Storage temperature: -20 ° C to 23 ° C

Battery case: ABS+PC

Intelligent lithium battery protection: power calculation, short circuit protection, over charge protection, over discharge protection, over current protection, USB charging and so on

Application: Intelligent door lock
