14.8V 3200mAh Lithium-ion Battery (18650)
Using LG Cells, For Medical Device with SMBUS Communication
- Model number:30AQ063-01
- Nominal voltage:14.8V
- Nominal capacity:3200mAh
- Battery cell:18650/3200mAh/3.7V
- Dimension:81*76*10.1mm（Max）
- Application:medical power supply
Product number: 30AQ063-01
Cell model：18650/3200mAh/3.7V
Battery specification: 18650-4S1P/14.8V/3200mAh
Nominal voltage：14.8V
Nominal capacity：3200mAh
Charging voltage: 16.8V
Charging current: ≤2.5A
Discharging current: 3A
Instant discharging current: 5A
End-off voltage: 12V
Internal resistance: ≤400mΩ
Battery weight: 210g
Product dimension: 81*76*10.1mm（Max）
Charging temperature：0～45℃
Discharging temperature: -20～55 ℃
Storage temperature: -20～45 ℃
Lithium-ion battery protection: short circuit protection, overcharge protection, over-discharge protection, overcurrent protection, equilibrium, Sumbus communication, etc.
Application field: medical power supply
1. Current: maximum sustainable discharge current is 5A.
2. Data communication management: adopt imported software management chip, SMBus communication function, precise data transmission and accurate temperature control so as to try our best to eliminate the security risks.
3. Battery characteristics: adopt imported LG battery with ultra large capacity.
4. The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and environmental protection.
