3.6V 6600mAh 18650 Samsung infrared night vision device ternary lithium battery

Product Number: 36AQ517-02

Cell model: 18650/3.6V/3350mAh (35E)

Battery specifications: 18650-1S2P/3.6V/6600mAh

Nominal voltage: 3.6V

Nominal capacity: 6600mAh

Charging voltage: 4.2V

Charging current: ≤2A

Discharge current: 1.5A

Instantaneous discharge current: 3A,3 to 4 seconds

Discharge cut-off voltage: 2.8V

Finished product internal resistance: ≤180mΩ

Battery weight: 120g

Product dimensions: 23.4*26.9*168.3mm

Charging temperature: 0-45℃

Discharge temperature: -10 to 60℃

Storage temperature: -20℃ to +23℃ (≤12 months)

Battery package: PA66+30%GF

Lithium battery protection: Overcharge, overdischarge, overcurrent and short-circuit protection functions

Application field: Portable industrial equipment and instruments

Product features

Imported battery cells and battery packs are safe and have a long cycle life.

Special shape design, meeting the customization requirements of various special structures, detachable and easy to replace.

The product is designed to withstand drops
