7.4V 900mAh 374446 polymer lithium battery for smart door lock

7.4V 900mAh smart door lock lithium battery

Product Number: 04DQ0348-03

Battery cell model: 374446/3.7V/900mAh

Battery specification: 374446-2S1P/7.4V/900mAh

Nominal voltage: 7.4V

Nominal capacity: 900mAh

Charging voltage: 8.4V

Micro USB: 5V charging

Charging current: ≤0.45A

Discharge current: 0.9A

Instantaneous discharge current: 1A

Discharge cut-off voltage: 6V

Finished product internal resistance: ≤240mΩ

Battery weight: 0.1Kg

Product dimensions: 60.2*50.2*10.2mm (Max)

Charging temperature: 0-45℃

Discharge temperature: -20 to 60 ℃

Storage temperature: -20 to 35 ℃

Battery housing: Engineering plastic

Lithium battery protection: short-circuit protection, overcharge protection, overdischarge protection, overcurrent protection, etc

Application fields: Smart door locks, smart home
